Model : QL-CT18FS this is a Pixel mapping waterproof LED strip light, with 18pcs 10w RGBW 4 in 1 LEDs, each LED control separately, beam angle 25°， or 45° for option. IP65 waterproof. DMX channels 8CH, 14CH, 26CH, 74CH.
Model : QL-CT18FS
this is a Pixel mapping waterproof LED strip light, with 18pcs 10w RGBW 4 in 1 LEDs, each LED control separately, beam angle 25°， or 45° for option. IP65 waterproof. DMX channels 8CH, 14CH, 26CH, 74CH.
LIGHT SOURCE
Lamp: 18 x 10w RGBW 4 in 1 LEDs,
Average Life Span>50,000h
OPTICS
Lens: 25°
COLOR SYSTEM
RGBW 4 in 1
EFFECTS
256 grade 0-100% square rate dimmer
Fast speed strobe
Effect macro and white light gradient effect
CONTROL AND PROGRAMMING
Control channel: 8, 14, 26, 38,74 control channel modes
Protocol: Standard DMX512 pixel mapping
Master/Slave control mode
Menu Display: LED display
DMX Signal Connection: 3-pin XLR input/output
BODY
Aluminum alloy die-casting structure
ELECTRONIC CONTROL TECHNOLOGY
Fixture reset is controlled through menu or light console
0-100% dimmer
Constant power control
Temperature sensor detection, intelligent light source power adjustment
DMX channel electronic level monitoring
Program edit available through the menu
DMX signal prompt
Fixture information query
Initial brightness setting for all colors
POWER SUPPLY
AC100-240V 50/60Hz
Switch power
Input Power: 190W
SAFETY PROTECTION
Overcurrent, overvoltage and overheating protection
IP RATE
IP65
WORKING POSITION
Any safety position to install
PHYSICAL
Fixture Dimension: 106 x 10 x 16 CM
Cardboard packing 1 in 1 : 120 X 15 X 20 CM, weight 9kgs
Flightcase packing 4 in 1 : 122 x 45 x 30 CM, weight 58kgs
N.W.:7 kg
